Olympus M.Zuiko 60mm F2.8 Macro Lens
For all micro-four thirds cameras
Check out Scott's Olympus 60mm macro len review, where port options are discussed.
Works great in the Olympus housing flat port!
This high quality macro lens is ideal for shooting a wide range of conditions, including applications such as underwater photography, landscape and portrait shooting. Featuring a closest focusing distance of 7.4 inches, this lens has excellent close-up capability with 1X magnification, and dust-/splash-proof construction. The lens incorporates 13 lens elements in 10 groups with extensive use of special glass materials such as ED (Extra-low Dispersion), HR (High Refractive index) and E-HR (Extra-High Refractive index) elements to completely eliminate the chromatic aberrations that can be noticeable with telephoto macro lenses.
The M.ZUIKO DIGITAL ED 60mm f2.8 Macro incorporates Olympus's exclusive MSC (Movie & Still Compatible) mechanism, which is based on a floating-type inner focusing system with three drive systems resulting in no change in the overall lens length during autofocusing. Other features such as focus limit switching and a shooting distance/magnification indicator window enhance macro shooting control and precision.
Olympus 60mm macro lens Compatible Cameras:
Works with all micro-four thirds mirrorless cameras such as the Olympus OM-D E-M1, E-M5, E-Pl1, E-Pl2, E-PL3, E-PM1, Panasonic GH2, GF2, GF3, GX1.
Olympus 60mm macro lens Compatible Housings:
Works (fits inside) with all Olympus PEN standard housings (the ones with *no lights*) expect for the E-PL1 housing. It wiill *not* fit inside PEN housings with lights (PT-EP05L, PT-EP06L), and it also will not fit in the E-PL1 housing. It does work with Nauticam Macro Port 65 for mirrorless housings, the Nauticam 12-50mm port, and with the Olympus PT-EP08, OM-D Housing standard port.
Olympus Zuiko 60mm F2.8 macro Specs:
|Focal Length||60mm (35mm equivalent focal length 120mm)|
|Lens construction||13 elements in 10 Groups - ED lens, 2 HR lenses, E-HR lens|
|Dust & Splash Proof||Yes|
|Angle of View||20 Degree|
|AF System||High-speed Imager AF (MSC)|
|Closest Focusing Distance||0.19m|
|Maximum Image Magnification||1.0x (35mm equivalent Maximum Image Magnification 2.0x)|
|Minimum Field Size||13 x 17mm|
|Number of Blades||7 (Circular Aperture Diaphragm)|
|Filter Size||Diameter 46mm|
|Dimension||Diameter 56 x 82mm|
Olympus 60mm macro underwater photos
Sawblade shrimp, taken with the Olympus 60mm macro lens in Anilao, Philippines
Dueling skeleton shrimp, photo taken by Scott Gietler in Anilao. Taken with the Olympus 60mm macro lens with Bluewater +7 diopter. Hope you can join one of our Anilao photo workshops
Tiny soft coral crab actively feeding at night, photo with an Olympus 60mm macro lens and Bluewater +7 diopter, E-M1 body. Read more about photographing marine life behavior.
